Category:
Close-to-Ceiling
Sub Category:
Edge Lit
Style:
Contemporary
Additional Info:
UGR - 23.4; Hi pot - DC-1550V; Edge-lit - Yes
Avg Rated Hours:
50000
Bulb Shape1:
Integrated LED
Bulb Type1:
LED
Color Temperature:
Warm White to Natural Light
Dimmable:
Yes-Dimmable
Each Height:
5.91
Each Length:
24.41
Each Width:
1.18
Length:
23.98
Lumens:
1650L-1870L
Tariff Code:
9405.11.8020
Warranty:
5 Year Limited - Fixtures
Amps:
0.200/0.087A
ANSI Base:
Integrated
BAA Compliant:
No
Beam Angle:
110
CA Prop-65:
Lead
CCT Selectable:
Yes
CEC:
California T24 2016 - 2022 JA8 Listed
CEC Terse:
Lawful for sale in California
CEC Web Text:
California T24 Listed
Country Of Origin:
Thailand
CRI:
90
Dimmable Down To:
100 to 10 percent
Dimmable Function:
120V only
Dimming Type:
Forward Phase or Reverse Phase
Each Cube:
0.0985
Each Quantity:
1
Efficacy:
68.75/73.33/77.92 LPW
ES Category:
Downlight Surface Mount
ES Unique ID:
ESID-2405325
FCC Compliant:
Yes
Feature 1:
Integrated LED featuring 24 watts, CCT Selectable from warm to natural light, 90 CRI
Feature 2:
Fixture is dimmable, selectable from 1650 to 1870 lumens
Feature 3:
Dimensions: 23.98 in L x 5.61 in W x1.06 in H
Feature 4:
White Finish with Acrylic Panel
Feature 5:
Ideal for utility, basements, kitchens, garages, bathrooms, bedrooms, hallways
Feature 6:
Rated for 50,000 hours
Feature 7:
5 Year Warranty
Feature 8:
Easy installation with included instructions
Feature 9:
Visit Satco.com for our entire line of BLINK products
Finish Family:
White
Fixture shape:
Rectangle
Flicker Free:
No
Incandescent Equivalent:
125W
Indoor Outdoor:
Indoor
Installation Notes:
Compatible with 3" & 4" J-box and pancake J-box
JA8 Compliant:
Yes
Lens Finish:
Frost
Lens Material:
Poly methyl methacrylate (PMMA)
Long Description:
Raising the bar for professional lighting, we present BLINK Pro Plus, a sleek design with advanced technology and features abound. BLINK's ENERGY STAR certified 62-1770 embodies a contemporary yet familiar aesthetic, a versatile solution suitable for a
Material:
Die-cast Aluminum
Mounting Procedure:
Ceiling
Operating Frequency:
60Hz
Operating Temp:
-20C (-4F) to +40C (+104F)
Pack Type:
Box
Power Factor:
0.9
Quantity In Pack:
1
R9 Value:
75
Replaceable Light Source:
No
RoHS Compliant:
Yes
Romance Copy:
Raising the bar for professional lighting, we present BLINK Pro Plus, a sleek design with advanced technology and features abound. BLINK's ENERGY STAR certified fixtures embody a contemporary yet familiar aesthetic, a versatile solution suitable for a
Safety Listing:
cETLus - Listed
SDS class:
LED_Fixture
Short Description:
BLINK PRO PLUS 24W 5.5 X 24
Temperature (CCT):
2700K/3000K/3500K/4000K/5000K
Title 20 Compliant:
No
Title 24 Compliant:
Yes
Total Harmonic Distortion:
<20%
Wattage Selectable:
No
Weight Lb.:
2.89
Standard Category:
Utility
Standard Subcategory:
Other Utility
Standard Style:
Contemporary
Standard Option:
Energy Star
, LED
, Prop 65
Standard Lumens:
1601-2600
Standard Kelvin:
4001-4500
