Category:
LED
Sub-Category:
HID Replacements
Volts:
120V-277V
Bulb Dimmable:
Yes-Dimmable
Bulb Hours:
50000
Bulb Kelvin:
5000K
Bulb Shape:
ED37
Diameter:
4.76
EA Length:
4.72
Harmonized Codes:
8539.52.0091
Length:
11.5
Lumens:
11700L/13200L/16500L
Shap Carton Width:
4.72
Ship Carton Height:
12.32
Ship Weight:
1.5
Warranty:
5 Year Limited - Hi-Pro
Weight:
1.5
Ballast Bypass Direct:
Ballast Bypass
Ballasting Requirements:
Ballast Bypass; Direct wire 120-277V line voltage; No ballast or external driver required
Beam Spread:
360
Bulb ANSI Base:
EX39
Bulb Base:
Mogul Extended
Bulb Finish:
Clear
Burning Position:
Universal
Candle Power:
850
Carton Cubic Feet:
0.1588
Cartons Per Unit:
1
CCT Selectable:
No
CEC:
Exempt - Base Not Regulated
CEC Terse:
Lawful for sale in California
CEC Web Text:
Lawful for sale
Color Temprature:
Natural Light
Country Of Origin:
China
CRI:
80+
Dimmable Function:
Only dimmable through wattage selection switch on lamp
Dimming Type:
Step Dimming
DLC Approved:
Yes
DLC Classification:
Standard
DLC ID:
S-93J453
DLC Primary Use:
Replacement Lamps for Outdoor Pole/Arm-Mounted Decorative Luminaires (Type B)
Efficacy:
195.00/194.12/194.12
Enclosed Fixture Use:
Yes
FCC Compliant:
Yes
Feature 1:
Wattage Selectable
Feature 2:
Type B - Ballast Bypass
Feature 3:
Range Voltage 120V-277V
Feature 4:
360-Degree Illumination
Feature 5:
Wet location rated
Feature 6:
Universal Operating Position
Feature 7:
Glass Lamp
Feature 8:
EX39 Mogul base
Feature 9:
Rated for Use in Enclosed Fixtures
HID Equivalent:
320W/400W/450W
Indoor Outdoor:
Indoor;Outdoor
Installation Notes:
Not for use in vapor tight fixtures.
JA8 Compliant:
No
Lamp Ballast Type A/B/C:
Type B
Lamp Filament:
LED
Location Rating:
Wet
Long Description:
SATCO|NUVO's LED HID Replacement Lamps are an energy efficient alternative to traditional HID lamps. This CCT selectable ED37 model is designed for use in type B ballast bypass applications, to make the transition to LED lamps easy. Enjoy long-lasting
Material:
Glass
Minimum Compartment Size:
Length: 13.74 in. Width: 16.97 in. Height: 16.97 in.
Operating Frequency:
50/60Hz
Operating Temp:
-30C (-22F) to +45C (+113F)
Pack Type:
Color Box
Power Factor:
>0.9
Quantity In Pack:
1
R9 Value:
1
RoHS Compliant:
Yes
Romance Copy:
SATCO|NUVO's LED HID Replacement Lamps are an energy efficient alternative to traditional HID lamps. Offered in a field selectable ED28 model or CCT selectable in ED28 and ED37 models. Designed for use in type B ballast bypass applications, these lamps
SDS class:
LED_Lamp
Short Description:
85W/LED/HID/ED37/850/EX39/CL
Style:
Utility
Surge Protection:
Built-in surge protection - 4KV
Technology:
LED
Title 20 Compliant:
Exempt
Title 24 Compliant:
No
Total Harmonic Distortion:
<20%
Wattage Selectable:
Yes
Watts:
60W/68W/85W
Standard Category:
Light Bulbs
Standard Subcategory:
LED Bulbs
