Category:
LED
Sub-Category:
LED T8
Volts:
120V-277V
Bulb Hours:
50000
Bulb Kelvin:
3000K/3500K/4000K/5000K/6500K
Bulb Shape:
T8
Diameter:
1
EA Length:
48.39
Harmonized Codes:
8539.52.0051
Length:
93.75
Lumens:
3500L/4400L/5500L
Shap Carton Width:
6.5
Ship Carton Height:
7.44
Ship Weight:
12.1
Warranty:
5 Year Limited - T8 LED Bulbs - Ballast Bypass
Weight:
0.98
BAA Compliant:
No
Ballasting Requirements:
Type B Ballast Bypass
Beam Spread:
210
Bulb ANSI Base:
Fa8
Bulb Base:
Single Pin
Bulb Finish:
White
Burning Position:
Universal
Carton Cubic Feet:
1.3542
Cartons Per Unit:
1
CCT Selectable:
Yes
CEC:
Exempt - Base Not Regulated
CEC Terse:
Lawful for sale in California
CEC Web Text:
Lawful for sale
Color Temprature:
Soft White to Daylight
Country Of Origin:
China
CRI:
80+
DLC Approved:
Yes
DLC Classification:
Standard
DLC ID:
S-HPN8SY
DLC Primary Use:
Internal Driver/Line Voltage (UL Type B) Lamps
Efficacy:
145.83/137.50/137.50 LPW
Enclosed Fixture Use:
Yes
Enclosure Rating:
Both
FCC Compliant:
Yes
Feature 1:
Field Selectable: 3 Wattage and 5 CCT
Feature 10:
Suitable for use in enclosed fixtures
Feature 2:
DLC Listed when used in Fa8 applications
Feature 3:
Optional R17d base caps included
Feature 4:
Includes C-clip for extra support where tubes connect
Feature 5:
PET Coated glass tube
Feature 6:
Compatible with optional 10W emergency driver
Feature 7:
Damp Location Rated
Feature 8:
Range Voltage 120V-277V
Feature 9:
210 Degree Beam Angle
Flourescent Equivalent:
40W/55W/70W
Housing Color:
White
Incandescent Equivalent:
100W
Includes:
(20) R17d Base Adapters and (10) Fastening Clips included per case
Installation Notes:
Not for use in vapor tight fixtures. Must use both sections; Provided support clips may differ from current PI Sheet (SN1394). Please refer to the Instruction Sheet provided in the master carton or downloaded from the website, https://www.satco.com/search/
IOT Enabled:
No
JA8 Compliant:
No
Lamp End Type:
Double Ended
Lamp Filament:
LED
Location Rating:
Damp
Long Description:
SATCO NUVO is always looking for the best ways to save time and costs on the job-site. The unique 2-piece design of the S11756 T8 lamp allows for reduced shipping costs and easier installation than a single 8-foot long tube by using two 4-foot sections tha
Material:
Glass
Minimum Compartment Size:
Length: 96.06 in. Width; 10.63 in. Height: 2.76 in.
Nominal Length:
96
NSF Approved:
Yes
Operating Frequency:
50/60Hz
Operating Temp:
-20C (-4F) to +45C (+113F)
Order In Multiples Of:
10
Pack Type:
Egg Crate
Power Factor:
0.9
Quantity In Pack:
10
R9 Value:
5
RoHS Compliant:
Yes
Romance Copy:
SATCO NUVO is always looking for the best ways to save time and costs on the job-site. The unique 2-piece design of this T8 lamp allows for reduced shipping costs and easier installation than a single 8-foot long tube by using two 4-foot sections that secu
SDS class:
LED_Lamp
Shatter Proof Text:
PET Coated
Short Description:
40T8/LED/96-CCT/BP/2PC
Style:
Utility
Technology:
LED
Title 20 Compliant:
Exempt
Title 24 Compliant:
No
Total Harmonic Distortion:
20%
Wattage Selectable:
Yes
Watts:
24W/32W/40W
Standard Category:
Light Bulbs
Standard Subcategory:
LED Bulbs
